BHN 601
(HU) NAMUR biztonsági szelep, kézi működtetésű - lakatolható
You can add comments on the request summary page.
BHN 601
(HU) NAMUR biztonsági szelep, kézi működtetésű - lakatolható
Please register here to access downloads for data sheets and 3D models.
| Product number | Options |
|---|
| Actuating force: | 18 N |
|---|---|
| Actuation: | Manually actuated |
| Air flow rate (P1=6 bar, ΔP=1 bar): | 900 l/min |
| Material body: | Aluminum |
| Medium: | Compressed air |
| Mounting type: | In-line |
| Operating pressure: | 1…10 bar |
| Orifice size: | DN 6 |
| Port orientation: | On two sides |
| Port size / Connection: | NAMUR-interface |
| Positional stability: | Bistable |
| Safety design: | NAMUR accessory for smart valve automation |
| Temperature range: | -10°C…+50°C |
