K2SA-41 - 110 AC

Filling unit, electrically operated - 10 bar - size FS-4 - Futura line

You can add comments on the request summary page.

K2SA-41 - 110 AC

Filling unit, electrically operated - 10 bar - size FS-4 - Futura line

Please register here to access downloads for data sheets and 3D models.

Product number	Air flow rate (P1=6 bar, ΔP=1 bar)	Port size / Connection	Size / Series
K2SA-014 - 24 AC	1400 l/min	G 1/4"	0
K2SA-014 - 24 DC	1400 l/min	G 1/4"	0
K2SA-014 - 110 AC	1400 l/min	G 1/4"	0
K2SA-014 - 230 AC	1400 l/min	G 1/4"	0
K2SA-41 - 24 AC	9000 l/min	G 1"	4
K2SA-41 - 230 AC	9000 l/min	G 1"	4
K2SA-114 - 110 AC	1400 l/min	G 1/4"	1
K2SA-114 - 230 AC	1400 l/min	G 1/4"	1
K2SA-138 - 24 AC	1400 l/min	G 3/8"	1
K2SA-138 - 24 DC	1400 l/min	G 3/8"	1
K2SA-138 - 110 AC	1400 l/min	G 3/8"	1
K2SA-138 - 230 AC	1400 l/min	G 3/8"	1
K2SA-212 - 110 AC	3400 l/min	G 1/2"	2
K2SA-238 - 24 AC	3400 l/min	G 3/8"	2
K2SA-238 - 110 AC	3400 l/min	G 3/8"	2
K2SA-238 - 230 AC	3400 l/min	G 3/8"	2
K2SA-434 - 24 AC	9000 l/min	G 3/4"	4
K2SA-434 - 24 DC	9000 l/min	G 3/4"	4
K2SA-434 - 110 AC	9000 l/min	G 3/4"	4
K2SA-434 - 230 AC	9000 l/min	G 3/4"	4

Air flow rate (P1=6 bar, ΔP=1 bar):	9000 l/min
Connection:	Form C (DIN EN 175301-803)
Duty cycle:	100% ED
IP protection:	IP 65
Material body:	Plastic
Material diaphragm:	NBR
Material seals:	NBR
Maximal Inlet operating pressure:	16 bar
Medium:	Compressed air
Port size / Connection:	G 1"
Power consumption:	2,5W / 3,0VA
Size / Series:	4
Temperature range:	-10°C…+50°C
Unit width:	85 mm
Voltage:	110 V AC
Voltage:	110 V AC
