P 531 701 G NPT
5/3-way pilot actuated valve - 1/4" NPT - spring return to middle position - centre closed - G-Series
You can add comments on the request summary page.
P 531 701 G NPT
5/3-way pilot actuated valve - 1/4" NPT - spring return to middle position - centre closed - G-Series
Please register here to access downloads for data sheets and 3D models.
| Product number | Options |
|---|
| Actuation: | Pneumatically actuated |
|---|---|
| Actuation pressure: | 3…10 bar |
| Air flow rate (P1=6 bar, ΔP=1 bar): | 1250 l/min |
| Material body: | Aluminum |
| Medium: | Compressed air |
| Mounting type: | G-series: in-line installationand manifold mounting possibl |
| Operating pressure: | 1…10 bar |
| Port orientation: | On two sides |
| Port size: | NPT G 1/8" |
| Port size / Connection: | NPT 1/4" |
| Positional stability: | 3-position, centre closed |
| Temperature range: | -10°C…+50°C |
| Ways: | 5/3-ways |
